SPECIFICATIONS

Brand Name: Reolink

Origin: Mainland China

High Definition: 8.0 Megapixels

Hign-concerned Chemical: None

Supported Operating Systems: Windows 7

Supported Operating Systems: Mac OS

Supported Operating Systems: Windows 8

Supported Operating Systems: Windows 10

Lens (mm): 2.8-8mm

Lens (mm): 4mm

Style: PT Camera

Connectivity: RJ45

Installation: Ceiling

Installation: Normal

Installation: Wall Mounted

Installation: Pendant Mount

Minimum Illumination(Lux): 100

Scene: Indoor and outdoor

Color Night Vision: YES

Megapixels: 8MP

Storage: None

Video Compression Format: H.264

Video Compression Format: H.265

IR Distance(m): 30 Meters (100ft) (LED:2pcs/20mil/850nm

Certification: CE

Certification: FCC

Dimensions (L x W x D)(mm): 228*147*110mm

Color: WHITE

Power Mode: Mains Electricity

Alarm Action: FTP Photo

Alarm Action: telefon Alarm

Alarm Action: Email Photo

Alarm Action: Local Alarm

Movement Range(Tilt): other

is_customized: No

Model Number: 8MP PT PoE Camera

Supported Mobile Systems: Android

Supported Mobile Systems: IOS

Smart home platform: Alexa

Smart home platform: Google Assistant

AI Functions: Human Detection

IP Rating: other

Special Features: Waterproof / Weatherproof

App name: other

TF Card: None

Digital Zoom: other

Power Supply(V): 12.0V

Audio Output: Two Way Audio

Power Consumption(W): <12W

Sensor: CMOS

Sensor Brand: Sony

Operating Temperature: -10°-60°

Shell Material: Plastic

Power Supply: With POE

Viewing Angle : 87°

Optical Zoom: none

Movement Range(Pan): 0°-360°

Rechargeable Battery: none

Image Sensor of Single-lens Cam: 1/2.7" CMOS Sensor

Image Sensor of Dual-lens Cam: 1/3"+1/2.8"CMOS Sensor

Video Resolution: 3840X2160(8Megapixels)@25FPS

Smart Alarms: Motion/human/vehicle /pet detection

Lens of Single-lens Cam: 4mm@F1.6,IR CUT

Lens of Dual-lens Cam: f=2.8mm@F=1.6, f=8mm@F=1.6

Day & Night: IR-cut filter &Auto-switching

Infrared Night Vision: 30 Meters(2pcs/20mil/850nm/3W)

Color Night Vision: Spotlight(2pcs, 6500K/450lm/15 Meters/4W)

POE Power: IEEE 802.3af, 48V active

DC Power: DC 12.0V 2A, <12W

Power: DC power port

Ethernet: One 10M/100Mbps RJ45

Storage: Micro SD card slot (Max. 256GB)

Pan &Tilt Range: Pan: 355°,Tilt: 0°~90°

Pan Speed: 90/8°-90°/s

Tilt Speed: 60/8°-60°/s

Preset Point: Up to 64

Auto Tracking: Support

Browsers Supported: Edge, Chrome, Firefox, Safari

Recording Modes: Motion/scheduled recording

Tracking Method: Digital Tracking; Pan/Tilt Tracking

Protocols & Standards: HTTPS, SSL, TCP/IP, UDP, HTTP, IPv4, UPnP, RTSP, RTMP, SMTP, NTP, DHCP, DNS, DDNS, FTP, P2P

Humidity: Operating humidity: 10% ~ 90%

Waterproof: IP65

Weight: 1.21KG

Limited Warranty: 2-year limited warranty

Manual Pan & Tilt, Auto Tracking

By manually controling the camera to move up and down, left and right, you can also keep an eye on other areas and broaden your field of view.

*The Dual-lens ip camera support Auto-zoom tracking and 6X hybrid zoom.





Samrt AI Detection & Accurate Alerts

The camera can analyze the shapes of people and vehicles or animals, thus sending you more accurate and meaningful alerts in real time.





Focus on What Really Matters

Customize the motion detection zone and sensitivity for more accurate alerts and peace of mind.



Dual Warning,Double Security

When the camera detects a suspicious person or object, its siren and spotlight will be activated to warn off the unwelcome. You can also manually turn on/off the siren and spotlight.

Two-Way Talk in Real Time

Built-in microphone & speaker allow you to listen and talk to whoever the camera catches in real time or warn off intruders.

Surveillance with 4K Clarity

The higher the resolution, the better the visual experience.

Various Modes for Your Various Needs

Multiple night vision modes: Black & White Mode, Color Mode, and Smart Mode.



PoE - Fast, Simplified & Lower-Cost Installation



                      H.265 HEVC                                     24/7 Recording Time

Works with Reolink IoT Devices

Pair camera with Reolink IoT devices like Reolink Floodlight PoE/WiFi and enjoy a more efficient and smart life style.

Build Your Reolink PoE System

Reolink provides a variety of security products for you to DIY your multi-functional PoE system.



Have Fun with Time Lapse

To capture a long-term dynamic process, a time lapse video is the best choice. Easy to use and fun to share.

*This function is not available when the camera is connected to the NVR.

Flexible Storage Options

IP Camera supports 24/7 continuous, motion-triggered or scheduled recording. It can be saved to microSD card, Reolink NVR or FTP server.

Certified Resistant & Durable

The sturdy housing makes this IP camera waterproof, working perfectly both inside and outside your house, in any harsh weather conditions.
